Запчасти Komatsu PC400LC-6LM FIG. A9-B7A ГЕНЕРАТОР - A С NON-HARDENED ШКИВ ДВИГАТЕЛЬ

|$0

600-821-9680

ALTERNATOR, 50A WITH NON-HARDENED PULLEY

1

SD1211-46000X0

STATOR ASSEMBLY

|$2

SD1230-19400X0

REAR BRACKET ASSEMBLY

2

SD2240-20610X0

BRACKET

3

SD1235-07900X0

HEAT SINK ASSEMBLY(+)

4

SD1235-08000X0

HEAT SINK ASSEMBLY()

5

SD8140-0603510

BOLT

6

SD3220-40000X0

SUPPORT

7

SD4215-00701X0

INSULATOR

8

SD4041-05710X0

BUSHING

9

SD5030-05200X0

WASHER

10

SD8140-0503010

BOLT

11

SD4215-00800X0

INSULATOR

12

SD4041-05700X0

BUSHING

13

SD6060-11920X0

CONDENSER

14

SD1235-07601X0

RESISTOR ASSEMBLY

15

SD1239-03600X0

CONNECTOR ASSEMBLY

16

SD4041-03700X0

BUSHING

17

SD1239-04310X0

CHARGE LAMP ASSEMBLY

18

SD6206-00200X0

BEARING

19

SD1291-00300X0

REGULATOR

20

SD3221-23220X0

COVER

21

SD1251-00600X0

COIL ASSEMBLY

22

SD1221-16700X0

ROTOR ASSEMBLY

|$24

SD1240-07400X0

FRONT BRACKET ASSEMBLY

23

SD2242-09010X0

BRACKET

24

SD6410-02000X0

SEAL

25

SD6206-00320X0

BEARING

26

SD4142-00900X0

ORING

27

SD2202-02200X0

COVER

28

SD5010-21500X0

BOLT

29

SD5010-04300X0

BOLT

30

SD3600-17300X0

COLLAR

31

SD3448-00440X0

FAN

32

SD2080-22400X0

PULLEY

33

SD3000-07800X0

WASHER

34

SD8264-1830010

NUT
