Запчасти Komatsu PC400LC-6LM FIG. T-A ЦИЛИНДР КОВША ASSEMBLY РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

208-63-02531

CYLINDER ASSEMBLY, BUCKET

1

208-63-73341

BARREL, CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL, DUST

4

07020-00000

FITTING, GREASE

5

208-63-73320

ROD

6

707-76-10140

BUSHING

7

208-70-12231

SEAL

8

07020-00000

FITTING, GREASE

9

707-27-16920

HEAD

10

198-63-94170

SEAL, DUST

11

07179-13126

RING, SNAP

12

707-52-90850

BUSHING

13

707-51-11030

PACKING, ROD

14

707-51-11630

RING

15

707-35-91640

RING, BACK-UP

16

07000-15150

O-RING

17

01010-82085

BOLT

18

707-88-75310

WASHER

19

707-36-16380

PISTON

20

01310-01216

SCREW

21

707-44-16180

RING, PISTON

22

707-39-16820

RING, WEAR

23

707-44-16910

RING

24

07001-05100

RING, BACK-UP

25

07000-15100

O-RING

26

208-63-73371

TUBE

27

208-63-73180

TUBE

28

01435-01055

BOLT

29

07000-13035

O-RING

30

707-88-87130

BRACKET

31

707-88-87140

CLAMP, CYLINDER

32

01010-81240

BOLT

33

01643-51232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-31232

WASHER

37

07000-13032

O-RING

38

07378-11000

HEAD

39

07371-31049

FLANGE, SPLIT

40

07372-21035

BOLT

41

01643-51032

WASHER
