Запчасти Komatsu PC400LC-6LM FIG. T-A ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

208-63-02501

CYLINDER ASSEMBLY, BOOM

1

208-63-53541

CYLINDER

2

707-76-10270

BUSHING

3

07145-00100

SEAL, DUST

4

07020-00675

FITTING, GREASE

5

07043-00108

PLUG

6

208-63-53520

ROD

7

707-76-11130

BUSHING

8

07145-00110

SEAL, DUST

9

707-71-32810

COLLAR

10

707-35-91640

RING, BACK-UP

11

07000-15150

O-RING

12

707-71-61111

PLUNGER

13

707-27-16920

HEAD

14

198-63-94170

SEAL, DUST

15

07179-13126

RING, SNAP

16

707-52-90850

BUSHING

17

707-51-11030

PACKING, ROD

18

707-51-11630

RING, BUFFER

19

707-35-91640

RING, BACK-UP

20

07000-15150

O-RING

21

01010-82085

BOLT

22

707-88-75310

WASHER

23

707-36-16380

PISTON

24

01310-01216

SCREW

25

707-44-16180

RING, PISTON

26

707-39-16820

RING, WEAR

27

707-44-16910

RING

28

07001-05100

RING, BACK-UP

29

07000-15100

O-RING

30

208-63-53571

TUBE, L.H

|$31

208-63-53671

TUBE, R.H

31

208-63-53181

TUBE, L.H

|$33

208-63-53281

TUBE, R.H

32

01435-01055

BOLT

33

07000-13035

O-RING

34

707-88-87110

BRACKET, L.H

|$37

707-88-87120

BRACKET, R.H

35

707-88-95770

BAND

36

01010-81240

BOLT

37

01643-51232

WASHER

38

07283-23442

CLIP

39

01643-31032

WASHER

40

01599-01011

NUT

41

01010-81025

BOLT

42

01643-31032

WASHER

43

07000-13032

O-RING

44

07378-11000

HEAD

45

07371-31049

FLANGE, SPLIT

46

07372-21035

BOLT

47

01643-51032

WASHER
