Запчасти Komatsu PC400LC-6LM FIG. A-AJ9 БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6151-22-1101

CYLINDER BLOCK ASSEMBLY

1

NSS

BLOCK, CYLINDER

2

6150-21-1490

BUSHING, CAMSHAFT

3

6150-29-1210

CAP, BEARING, NO. 1, 2, 3, 4, 5, 6

4

6150-29-1250

CAP, BEARING, NO. 7

5

04025-00408

PIN, SPRING

6

04020-00514

PIN

7

6150-21-1710

BOLT

8

01643-31645

WASHER

9

07043-50108

PLUG

10

07043-50211

PLUG

11

07043-50617

PLUG

12

07040-12414

PLUG

13

07002-22434

O-RING

14

07040-13016

PLUG

15

07002-23034

O-RING

16

07042-00312

PLUG

17

07046-43016

PLUG

18

07046-44016

PLUG

19

07046-22516

PLUG

20

07046-21210

PLUG

21

07046-43516

PLUG

22

04020-00820

PIN, DOWEL

23

6150-21-1170

TUBE

24

6150-41-2430

PIN

25

6150-41-2440

PIN

26

6150-21-4770

PIN, DOWEL

27

6150-41-2430

PIN

28

04020-01024

PIN, DOWEL

29

6110-53-5910

PLUG

30

07005-01412

GASKET

31

04025-00512

PIN, SPRING

32

01050-51012

BOLT

33

07005-01012

GASKET

34

01050-51420

BOLT

35

07005-01412

GASKET

36

6151-22-2220

LINER, CYLINDER

37

6150-21-2230

O-RING, LOWER

38

6150-21-2240

O-RING, UPPER

39

6150-21-2250

SEAL, CREVICE

40

6151-22-1810

NOZZLE, PISTON COOLING

41

01435-00816

BOLT
