Запчасти Komatsu PC400LC-6LK СТАРТЕР KW ДВИГАТЕЛЬ

|$0

600-813-8310

MOTOR, STARTING - 11 KW

1

SD1310-10030X0

YOKE ASSEMBLY

2

SD4141-26410X0

PACKING

3

SD2240-24143X0

BRACKET, REAR

4

SD1331-04300X0

BRUSH HOLDER ASSEMBLY

5

SD5250-02800X0

SPRING, BRUSH

6

SD5000-10500X0

SCREW

7

SD6414-02940X0

O-RING

8

SD3040-12100X0

PLATE

9

SD1320-07830X0

ARMATURE ASSEMBLY

10

SD6206-01110X0

BEARING, BALL

11

SD6206-01120X0

BEARING, BALL

12

SD8167-0719060

BOLT

13

SD2245-00830X0

CASE, GEAR

14

SD5031-05700X0

SHIM

15

SD2441-03200X0

SHAFT

16

SD2244-06902X0

HOLDER, CENTER

17

SD6410-01000X0

SEAL, OIL

18

SD6206-01710X0

BEARING, BALL

19

SD1361-04800X0

PINION CLUTCH ASSEMBLY

20

SD3661-02000X0

STOPPER, PINION

21

SD5221-01200X0

HOOK

22

SD5058-04200X0

RING, RETAINING

23

SD5010-27430X0

BOLT

24

SD4141-26311X0

PACKING

25

SD1372-04200X0

LEVER ASSEMBLY

26

SD3600-17800X0

ROD

27

SD4223-05200X0

HOLDER, LEVER

28

SD5201-10100X0

COIL, SPRING

29

SD2407-02101X0

COLLAR

30

SD2244-06821X0

BRACKET, CENTER

31

SD2046-14100X9

CASE ASSEMBLY

32

SD2620-10500X9

METAL

33

SD5010-26200X0

BOLT

34

SD5010-26220X0

BOLT

35

SD1350-10932X9

SWITCH ASSEMBLY, ENGAGE

36

SD5010-27300X0

BOLT

37

SD1599-0010010

RELAY, SAFETY

38

SD1331-04300X9

BRUSH HOLDER ASSEMBLY

39

SD5250-02800X0

SPRING, BRUSH

40

SD2660-07400X6

BRUSH

41

SD2660-07400X7

BRUSH
