Запчасти Komatsu PC400LC-6LK ВОДЯНАЯ ПОМПА ДВИГАТЕЛЬ

|$0

6151-62-1101

PUMP, WATER

1

NSS

BODY

2

6150-61-1510

SEAL, OIL

3

06030-06004

BEARING, BALL

4

06030-06304

BEARING, BALL

5

6150-61-1350

SPACER

6

04065-05220

RING, SNAP

7

6151-61-1360

SPACER

8

6211-61-1521

SEAL, WATER

9

6151-62-1310

SHAFT

10

6151-61-1210

IMPELLER

11

6150-61-1410

GEAR

12

6151-61-1151

COVER

13

6151-61-1162

GASKET

14

01010-80816

BOLT

15

01602-20825

WASHER, SPRING

16

07000-62115

O-RING

17

01011-81010

BOLT

18

01640-21016

WASHER

19

6150-62-6510

CONNECTOR

20

02893-05037

O-RING

21

6150-61-1821

GASKET

22

01010-81020

BOLT

23

6151-61-6311

CONNECTOR, WATER OUTLET

24

6150-61-1821

GASKET

25

01010-81030

BOLT

26

01010-81035

BOLT

27

6150-22-6410

HOUSING, THERMOSTAT

28

6250-22-6490

GASKET

29

01437-01065

BOLT

30

09482-20000

VALVE

31

6210-61-6260

CONNECTOR, WATER INLET

32

6210-61-6441

GASKET

33

01010-81025

BOLT

34

600-421-6630

THERMOSTAT

35

6162-13-6440

SEAL

36

01010-81085

BOLT

37

08053-01510

CLIP

38

6631-11-6390

SPACER

39

04434-51610

CLIP
