Запчасти Komatsu PC400LC-6LK ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LK - ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ
4
5
3
6
1
2
3
7
12
9
13
11
8
10

Артикул

Название

Примечание

Количество

1

6152-32-2510

PISTON

2

6151-31-2410

PIN

3

04065-04818

RING, SNAP

|$3

6150-32-2030

PISTON RING ASSEMBLY

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$7

6151-31-3101

CONNECTING ROD ASSEMBLY

7

NSS

ROD, CONNECTING

8

NSS

CAP

9

6150-31-3130

BUSHING

10

6150-31-3310

BOLT

11

02400-10413

PIN

|$13

6150-31-3040

BEARING, CONNECTING ROD (STANDARD)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$16

6150-39-3040

BEARING, CONNECTING ROD (0.25MM UNDERSIZE)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$19

6150-38-3040

BEARING, CONNECTING ROD (0.50MM UNDERSIZE)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$22

6150-37-3040

BEARING, CONNECTING ROD (0.75MM UNDERSIZE)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$25

6150-36-3040

BEARING, CONNECTING ROD (1.00MM UNDERSIZE)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

Выбрано товаров: 28
