Запчасти Komatsu PC400LC-6LK КОЛЕНВАЛ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LK - КОЛЕНВАЛ ДВИГАТЕЛЬ
6
4
3
2
1
6
5
6
5

Артикул

Название

Примечание

Количество

|$0

6151-35-1010

CRANKSHAFT ASSEMBLY

1

NSS

CRANKSHAFT

2

6150-35-1120

GEAR, CRANKSHAFT

3

6150-31-1130

KEY

|$4

6150-21-8010

BEARING, MAIN (STANDARD)

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

6

6150-21-8050

BEARING, THRUST ASSEMBLY (STANDARD)

|$8

6150-29-8010

BEARING, MAIN (0.25MM UNDERSIZE)

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

|$11

6150-28-8010

BEARING, MAIN (0.50MM UNDERSIZE)

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

|$14

6150-27-8010

BEARING, MAIN (0.75MM UNDERSIZE)

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

|$17

6150-26-8010

BEARING, MAIN (1.00MM UNDERSIZE)

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

6

6150-29-8050

BEARING, THRUST ASSEMBLY (0.25MM OVERSIZE)

6

6150-28-8050

BEARING, THRUST ASSEMBLY (0.50MM OVERSIZE)

6

6150-27-8050

BEARING, THRUST ASSEMBLY (0.75MM OVERSIZE)

6

6150-26-8050

BEARING, THRUST ASSEMBLY (1.00MM OVERSIZE)

Выбрано товаров: 24
