Запчасти Komatsu PC400LC-6LK FIG NO. H-A ОСНОВН. КЛАПАН АКТУАТОР (/) ГИДРАВЛИКА

1

723-46-41110

VALVE

2

723-46-41120

VALVE

|$4

723-46-40100

VALVE ASSEMBLY

3

NSS

SLEEVE

4

NSS

SUB ASSEMBLY, PISTON

5

NSS

SPRING

6

NSS

SEAL

7

700-93-11320

O-RING

8

723-46-41950

RING

9

07002-13634

O-RING

|$12

723-46-40300

VALVE ASSEMBLY

10

NSS

...SLEEVE

11

NSS

...PISTON

12

NSS

...SPRING

13

NSS

...SEAL

14

700-93-11320

O-RING

15

723-46-41950

RING

16

07002-13634

O-RING

|$20

723-46-40601

VALVE ASSEMBLY

17

NSS

SLEEVE

18

NSS

SUB ASSEMBLY, PISTON

19

NSS

SPRING

20

NSS

SEAL

21

700-93-11320

O-RING

22

723-46-41950

RING

23

07002-13634

O-RING

|$28

723-46-44100

VALVE ASSEMBLY

24

NSS

SLEEVE

25

NSS

SUB ASSEMBLY, PISTON

26

NSS

SPRING

27

NSS

SEAL

28

700-93-11320

O-RING

29

723-46-41950

RING

30

07002-13634

O-RING

|$36

723-46-45100

VALVE ASSEMBLY . . . . . . . . . . . . . . . . 3

31

NSS

SLEEVE. . . . . . . . . . . . . . . . . . . . 1

32

NSS

SUB ASSEMBLY, PISTON. . . . . . . . . . . . . 1

33

NSS

SPRING. . . . . . . . . . . . . . . . . . . . 1

34

NSS

SEAL

35

700-93-11320

O-RING

36

723-46-41950

RING

37

07002-13634

O-RING

|$44

723-46-45200

VALVE ASSEMBLY

38

NSS

SLEEVE

39

NSS

VALVE SUB ASSEMBLY

40

NSS

SPRING

41

NSS

SEAL

42

700-93-11320

O-RING

43

723-46-41950

RING

44

07002-13634

O-RING

45

723-46-41980

RETAINER
