Запчасти Komatsu PC400LC-6LK FIG NO. H-A ОСНОВН. КЛАПАН (/) ГИДРАВЛИКА

Схема запчастей Komatsu PC400LC-6LK - FIG NO. H-A ОСНОВН. КЛАПАН (/) ГИДРАВЛИКА
1
24
3
10
20
30
9
37
18
29
15
36
8
20
28
35
7
14
29
36
8
15
19
26
5
12
33
22
13
6
27
34
21
4
25
11
32
22
23
27
34
6
13
2
1
1
1
17
39
41
40
43
42
43
44
45
38
16
31

Артикул

Название

Примечание

Количество

|$54

723-46-06900

SUB ASSEMBLY, BODY

1

723-46-41110

VALVE

2

723-46-41120

VALVE

|$57

723-46-40100

VALVE ASSEMBLY

3

NSS

SLEEVE

4

NSS

SUB ASSEMBLY, PISTON

5

NSS

SPRING

6

NSS

SEAL

7

700-93-11320

O-RING

8

723-46-41950

RING

9

07002-13634

O-RING

|$65

723-46-40300

VALVE ASSEMBLY

10

NSS

SLEEVE

11

NSS

PISTON

12

NSS

SPRING

13

NSS

SEAL

14

700-93-11320

O-RING

15

723-46-41950

RING

16

07002-13634

O-RING

|$73

723-46-40601

VALVE ASSEMBLY

17

NSS

SLEEVE

18

NSS

SUB ASSEMBLY, PISTON

19

NSS

SPRING

20

NSS

SEAL

21

700-93-11320

O-RING

22

723-46-41950

RING

23

07002-13634

O-RING

|$81

723-46-44100

VALVE ASSEMBLY

24

NSS

SLEEVE

25

NSS

SUB ASSEMBLY, PISTON

26

NSS

SPRING

27

NSS

SEAL

28

700-93-11320

O-RING

29

723-46-41950

RING

30

07002-13634

O-RING

|$89

723-46-45100

VALVE ASSEMBLY

31

NSS

SLEEVE

32

NSS

SUB ASSEMBLY, PISTON

33

NSS

SPRING

34

723-46-42920

SEAL

35

700-93-11320

O-RING

36

723-46-41950

RING

37

07002-13634

O-RING

|$97

723-46-45200

VALVE ASSEMBLY

38

NSS

SLEEVE

39

NSS

VALVE SUB ASSEMBLY

40

NSS

SPRING

41

723-46-42920

SEAL

42

700-93-11320

O-RING

43

723-46-41950

RING

44

07002-13634

O-RING

45

723-46-41980

RETAINER

Выбрано товаров: 52
