Запчасти Komatsu PC400LC-6LK FIG. H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН - COMPLETE ASSEMBLY ГИДРАВЛИКА

|$0

723-47-19103

VALVE ASSEMBLY, MAIN CONTROL (COMPLETE)

|$1

723-46-06900

BODY SUB ASSEMBLY

1

NSS

BLOCK, VALVE

2

NSS

SPOOL

3

NSS

SPOOL

4

NSS

SPOOL

5

NSS

SPOOL

6

NSS

SPOOL

7

723-46-15130

PLUG

8

723-46-15650

PLUG

9

723-46-15140

PLUG

10

07002-10823

O-RING

11

708-7T-16460

BALL

12

723-46-15120

RETAINER

13

723-46-15880

RETAINER

14

723-46-14110

SPRING

15

723-46-14170

SPRING

16

723-46-14250

SPRING

17

723-46-14131

SPRING

18

723-46-15620

RETAINER

19

723-46-15610

CASE

20

723-46-14260

SPRING

21

723-46-14220

SPRING

22

723-46-15630

PLUG

23

709-25-11390

O-RING

24

723-46-15640

PISTON

25

702-73-11510

SEAL

26

723-46-16210

RETAINER

27

723-46-15110

CASE

28

07430-71380

O-RING

29

01252-60820

BOLT

30

723-46-15410

CASE

31

723-46-15420

RETAINER

32

723-46-15450

PLUG

33

07002-13034

O-RING

34

723-46-14150

SPRING

35

723-46-15430

PISTON

36

706-86-51180

PLUG

37

723-46-15150

VALVE

38

723-46-14150

SPRING
