Запчасти Komatsu PC400LC-6LK FIG. A9-B7A ГЕНЕРАТОР - A С NON-HARDENED ШКИВ ДВИГАТЕЛЬ

|$0

600-825-3151

ALTERNATOR, 35A WITH NON-HARDENED PULLEY

1

KD0-35100-0280

ROTOR ASSEMBLY

2

KD1-33923-0790

COLLAR

3

KD0-09201-0870

BEARING, BALL

4

KD0-35200-0270

STARTER ASSEMBLY

5

KD0-35300-0130

FRONT BRACKET ASSEMBLY

6

KD0-09201-0880

BEARING, BALL

7

KD0-35926-0070

RETAINER

8

KD0-35951-0060

PACKING

9

KD0-35926-0090

RETAINER

10

KD1-33926-0730

RETAINER

11

KD0-0275-06802

BOLT

12

KD0-35411-0560

PULLEY, NON-HARDENED

13

KD0-35421-0140

FAN

14

KD1-0335-16002

WASHER, SPRING

15

KD0-0280-16022

NUT

16

KD0-35120-0450

FIELD COIL

|$17

KD0-35700-0660

REAR BRACKET ASSEMBLY

17

KD0-35710-0750

BRACKET

18

KD0-35730-0510

RECTIFIER ASSEMBLY

19

KD0-09170-2500

CONDENSER

20

KD0-35943-0150

INSULATOR

21

KD0-35923-0130

COLLAR

22

KD0-35943-0160

INSULATOR

23

KD0-35943-0140

INSULATOR

24

KD0-35943-0170

INSULATOR

25

KD0-35784-0190

BAR, CONNECTOR

26

KD0-35786-0320

TERMINAL, PLATE

27

KD0-35719-0150

REGULATOR

28

KD0-35761-0181

COVER
