Запчасти Komatsu PC400LC-6LK FIG. R-A ГУСЕНИЦЫ - СТАНДАРТН. ХОДОВАЯ

Схема запчастей Komatsu PC400LC-6LK - FIG. R-A ГУСЕНИЦЫ - СТАНДАРТН. ХОДОВАЯ
3
5
10
9
10
4
11
7
6
7
8
1
2

Артикул

Название

Примечание

Количество

|$0

208-32-03181

SHOE ASSEMBLY, TRACK (600 MM WIDE)

1

208-32-61110

SHOE, TRACK

2

208-32-51210

BOLT, SHOE

3

208-32-51220

NUT, SHOE

|$4

208-32-00411

LINK ASSEMBLY, TRACK

4

208-32-61121

LINK, L.H. TRACK

5

208-32-61131

LINK, R.H. TRACK

6

208-32-61140

BUSHING, REGULAR

7

154-32-11283

SEAL, DUST (REGULAR)

8

154-820-1153

PIN, REGULAR

9

208-32-61170

BUSHING, MASTER

10

208-32-61260

SEAL, DUST (MASTER)

11

208-32-51190

PIN, MASTER

|$14

208-32-03191

SHOE ASSEMBLY, TRACK (700 MM WIDE)

1

208-32-61310

SHOE, TRACK

2

208-32-51210

BOLT, SHOE

3

208-32-51220

NUT, SHOE

|$18

208-32-00411

LINK ASSEMBLY, TRACK

|$19

208-32-03201

SHOE ASSEMBLY, TRACK (800 MM WIDE)

1

208-32-61320

SHOE, TRACK

2

208-32-51210

BOLT, SHOE

3

208-32-51220

NUT, SHOE

|$23

208-32-00411

LINK ASSEMBLY, TRACK

|$24

208-32-03211

SHOE ASSEMBLY, TRACK (900 MM WIDE)

1

208-32-61340

SHOE, TRACK

2

208-32-51210

BOLT, SHOE

3

208-32-51220

NUT, SHOE

|$28

208-32-00411

LINK ASSEMBLY, TRACK

|$29

208-32-05050

SERVICE KIT, SHOE BOLT AND NUT

|$30

208-32-51210

BOLT, SHOE

|$31

208-32-51220

NUT, SHOE

Выбрано товаров: 31
