Запчасти Komatsu PC400LC-6LK FIG. A-B7A СМАЗЫВ. НАСОС ДВИГАТЕЛЬ

|$0

6151-51-1005

PUMP ASSEMBLY, LUBRICATING OIL

|$1

6151-51-1303

SHAFT ASSEMBLY

1

6151-51-1313

SHAFT

2

6151-51-1511

GEAR

|$4

6151-51-1102

COVER ASSEMBLY

3

NSS

COVER

4

6151-51-1430

BUSHING

5

6151-51-1320

SHAFT

6

6151-51-1610

GEAR

|$9

6151-51-1203

BODY ASSEMBLY

7

NSS

BODY

8

6151-51-1430

BUSHING

|$12

6151-51-1401

GEAR ASSEMBLY

9

NSS

GEAR

10

6151-51-1421

BUSHING

11

6136-52-1640

VALVE

12

6136-52-1650

SPRING

13

6136-52-1660

PLUG

14

01010-80825

BOLT

15

6136-52-1620

PIN

16

6151-51-1710

SHIM, 0.8MM

17

6150-51-1710

RING

18

6150-51-1720

RING

19

01010-81025

BOLT

20

01010-81035

BOLT

21

01643-31032

WASHER
