Запчасти Komatsu PC400LC-6LK FIG. A-AC ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ

1

6152-32-2510

PISTON, ENGINE

2

6151-31-2410

PIN, PISTON

3

04065-04818

RING, SNAP

|$3

6150-32-2030

RING ASSEMBLY, PISTON

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$7

6151-31-3101

ROD ASSEMBLY, CONNECTING

7

NSS

ROD, CONNECTING

8

NSS

CAP

9

6150-31-3130

BUSHING

10

6150-31-3310

BOLT

11

02400-10413

PIN

|$13

6150-31-3040

BEARING, CONNECTING ROD (STD)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$16

6150-39-3040

BEARING, CONNECTING ROD (0.25MM UNDER)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$19

6150-38-3040

BEARING, CONNECTING ROD (0.50MM UNDER)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$22

6150-37-3040

BEARING, CONNECTING ROD (0.75MM UNDER)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER

|$25

6150-36-3040

BEARING, CONNECTING ROD (1.00MM UNDER)

12

NSS

BEARING HALF, UPPER

13

NSS

BEARING HALF, LOWER
