Запчасти Komatsu PC400LC-6LK FIG. K-A КАБИНА - КРЫШКА ПАНЕЛИ С ОБОГРЕВ-ЛЕМ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-06-23940

STRAP, TIE

2

09414-11053

CAP

3

20Y-06-23710

STAY

4

01370-00512

SCREW

5

20Y-06-23720

STAY

6

01370-00512

SCREW

7

20Y-06-23730

STAY

8

01370-00512

SCREW

9

20Y-06-23740

STAY

10

01023-10408

SCREW

11

20Y-06-23750

BRACKET

12

01023-10510

SCREW

13

20Y-06-23760

BRACKET

14

01023-10510

SCREW

15

20Y-06-23770

CLIP

16

20Y-54-36981

PACKING

17

20Y-06-23790

CAP

18

20Y-979-2170

GRILLE

19

20Y-06-23810

STAY

20

01370-00512

SCREW

21

20Y-06-23431

SWITCH, BUZZER STOP

22

20Y-06-23441

SWITCH, SWING LOCK

23

20Y-06-23950

SWITCH, WIPER

24

20Y-06-23421

SWITCH, LIGHT

25

08086-20000

SWITCH

26

20Y-06-23471

LIGHTER, CIGAR

27

20Y-06-23820

HOLDER

28

01023-10510

SCREW

29

20Y-06-23211

PANEL

30

20Y-06-23461

SWITCH, HEATER

31

207-06-61131

SWITCH ASSEMBLY, MACHINE PUSH-UP

32

7825-30-1301

DIAL, FUEL

33

01252-40410

BOLT

34

01601-20410

WASHER
