Запчасти Komatsu PC400LC-6LK FIG. K-AA КАБИНА - ОСНОВ. - РЫЧАГ С КЛАПАНОМ PPC КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-06-25110

BASE, OPERATOR'S CAB

2

20Y-06-24121

SWITCH ASSEMBLY

3

01641-21223

WASHER

4

569-06-61960

RELAY

5

01435-00610

BOLT

6

208-06-68123

HARNESS ASSEMBLY

7

283-06-16110

BOX, FUSE

8

195-Z11-2290

COVER

9

20Y-06-24130

SWITCH

10

283-06-16190

FUSE, 10A

11

205-06-73180

FUSE, 15A

12

22W-06-13160

FUSE, 20A

|$13

08041-02500

FUSE, 25A

13

20Y-06-21460

CLIP

14

20Y-06-23960

CLIP

15

01023-10625

SCREW

16

20Y-979-2130

BOX ASSEMBLY

17

01435-01016

BOLT

18

20Y-979-2221

DUCT

19

01435-00610

BOLT

20

20Y-979-2231

DUCT

21

01435-00610

BOLT

22

20Y-979-2242

DUCT

23

01435-00610

BOLT

24

7861-94-0850

RESISTOR

25

01435-00820

BOLT

26

203-06-56230

BUZZER ASSEMBLY

27

01435-00610

BOLT

28

7834-20-5006

CONTROLLER

29

01435-00880

BOLT

30

20Y-06-25130

RELAY BOX

31

01435-00630

BOLT

32

20Y-06-24220

SHEET

33

08051-00801

CLIP

34

20Y-06-23521

LOCK

35

01435-00820

BOLT

36

08017-30701

CONDUIT

37

01010-51020

BOLT

38

01643-31032

WASHER
