Запчасти Komatsu PC400LC-6LK FIG. H-9A ОСНОВН. НАСОС - СЕРВОКЛАПАН ГИДРАВЛИКА

|$1

708-2H-03120

SERVO VALVE ASSEMBLY

|$2

708-2H-03800

BODY ASSEMBLY

1

NSS

BODY

2

NSS

PLUG

3

NSS

EXPANDER

4

708-2H-25650

ORIFICE

5

708-2L-25211

SOLENIOD ASSEMBLY

6

07000-B2016

O-RING

7

01252-60612

BOLT

8

708-2L-25223

SLEEVE

9

708-2L-25232

SPOOL

10

708-2L-25291

SEAT

11

708-2L-25250

SPRING

12

708-2L-25261

SPRING

13

708-2L-25281

PISTON

14

07040-11007

PLUG

15

708-2L-23920

O-RING

16

708-2H-25370

LEVER

17

708-2L-25311

PIN

18

708-2L-25330

BEARING

19

708-2L-25321

WASHER

20

01580-00605

NUT

21

708-2L-25340

PLUG

22

01580-11811

NUT

23

708-2H-19250

O-RING

24

708-2L-25382

PLUG

25

07000-B2010

O-RING

26

04065-01610

RING
