Запчасти Komatsu PC400LC-6LC FIG NO. C-A РАДИАТОР И МАСЛООХЛАДИТЕЛЬ ВЫС. ALTITUDE СИСТЕМА ОХЛАЖДЕНИЯ

1

208-03-68350

RADIATOR CORE ASSEMBLY

2

208-03-58370

CAP

3

205-03-62660

PLUG

4

07000-01007

O-RING

5

205-03-71230

HOSE

6

20Y-03-11330

CLIP

7

01010-81225

BOLT

8

01643-31232

WASHER

9

208-03-68340

OIL COOLER ASSEMBLY

10

01010-81225

BOLT

11

01643-31232

WASHER

12

01010-81225

BOLT

13

01643-31232

WASHER

14

207-03-51171

SEAL

15

207-03-51181

SEAL

16

208-03-61250

SHEET

17

208-03-61240

SHEET

18

208-03-61260

SHEET

19

208-03-61130

FRAME

20

208-03-61140

FRAME

21

208-03-61171

NET

22

01434-10620

BOLT

23

01643-30623

WASHER

24

208-03-68130

SHROUD

25

208-03-A1120

NET

26

01010-81225

BOLT

27

01643-31232

WASHER

28

208-03-68320

NET

29

01010-81025

BOLT

30

01643-31032

WASHER

31

208-03-61211

TUBE

32

07283-24949

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER

35

208-03-61221

BRACKET

36

07000-03045

O-RING

37

01010-51240

BOLT

38

01643-51232

WASHER

39

01010-51025

BOLT

40

01643-31032

WASHER
