Запчасти Komatsu PC400LC-6LC СТАРТЕР MT - ТИП - V ДВИГАТЕЛЬ

|$0

1304 953 H91

MOTOR, STARTING (PRODUCTION ONLY)

|$1

1307 569 H91

MOTOR, STARTING (SERVICE)

1

1307 313 H1

FRAME

2

88 797

BUSHING

3

1223 256 H1

ARMATURE

4

1228 605 H1

FIELD COIL

5

1307 314 H1

LEAD

6

N/A

THERMOSTAT & CONN. ASM

7

1223 258 H91

LEVER, HOUSING

8

1307 315 H1

BUSHING, LEVER HOUSING

9

1228 604 H1

DRIVE ASM

10

1228 448 H91

DRIVE, HOUSING

11

1211 288 H1

BUSHING, DRIVE HOUSING

12

1284 359 H1

SWITCH

13

1303 561 H1

BRUSH

14

1283 451 H1

SPRING BRUSH

15

1284 360 H91

BRUSH PLATE ASM

16

1228 450 H1

PLUNGER

17

1210 071 H1

BOOT

18

1210 073 H1

PLUNGER, SPRING

19

1307 316 H1

SHIFT, LEVER

20

1211 356 H1

WASHER

21

1211 286 H1

WASHER, BRAKE

22

1232 885 H1

WASHER, THRUST

23

120 239

WASHER, LOCK

24

N/A

NUT, TERMINAL SHIELD

25

1211 267 H1

NUT, FIELD COIL CONNECTION TO SWITCH ATCH

26

19 839 R1

NUT, PLUNGER ROD GUIDE ADJUSTING

27

1305 531 H1

NUT, ASM SHUNT LEAD TO SWITCH ATCH

28

120 238

NUT, TERM-CE FRAME

29

1211 267 H1

NUT & WASHER ASSEMBLY - CE FRAME

30

1211 292 H1

SCREW, BRUSH LEAD & FLD COIL LEAD

31

1223 263 H1

SCREW & WASHER ASSEMBLY - CE FRAME ATCH

32

1283 448 H1

SCREW, CONNECTOR TO FIELD ATCH

33

1245 105 H1

SCREW, DRIVE HSG ATCH

34

1245 107 H1

SCREW, LEVER HSG ATCH

35

1245 108 H1

SCREW, POLE SHOE

36

1283 448 H1

SCREW & WASHER ASM.-SWITCH ATCH

37

NOT USED

38

1210 070 H1

WASHER, PLUNGER ASM

39

1307 320 H1

WASHER, TERM - CE FRAME

40

1307 317 H1

CONNECTOR, FLD TERM TO SWITCH

41

1307 318 H1

CUP, OIL RESERVOIR - CE

42

1211 277 H1

CUP, OIL RESERVOIR - DE

43

1307 318 H1

CUP, OIL RESERVOIR - LEVER HSG

44

1211 151 H1

GASKET, INSPECTION PLUG - LEVER HSG

45

1228 453 H1

INSULATOR, FLD COIL - CE

46

1210 061 H1

INSULATOR, FLD TERM (INSIDE FRAME)

47

1210 062 H1

INSULATOR, FLD TERM (OUTSIDE FRAME)

48

1223 269 H91

INSULATION, PKG - CE TERM

49

NOT USED

50

1277 066 H1

LEAD, CE TERM TO SOLENOID SWITCH

51

1307 319 H1

O-RING, BETWEEN SWITCH & LEVER HSG

52

347 360 R1

O-RING, BETWEEN DR HSG & LEVER HSG

53

22 411 R1

O-RING, BETWEEN LEVER HSG & FRAME

54

1307 321 H1

O-RING, ON MOTOR FRAME CE END

55

352 219 R1

O-RING, SHIFT LEVER SHAFT (3/8 IN O.D.)

56

355 967 R1

O-RING, SHIFT LEVER SHAFT (1/2 IN O.D.)

57

1228 454 H1

PIN, SPRING (IN FRAME)

58

1210 066 H1

PLUG, INSPECTION - LEVER HSG

59

1228 455 H1

PLUG, DRIVE HSG MOUNTING HOLES

60

1211 263 H1

POLE, SHOE

61

1210 072 H1

RETAINER, PLUNGER SPRING (1 13/64 HOLE)

62

1210 074 H1

RETAINER, PLUNGER SPRING (13/32 HOLE)

63

NOT USED

64

1211 285 H1

SEAL, OIL - LEVER HSG

65

1211 152 H1

SHAFT, SHIFT LEVER

66

NSS

TERMINAL, SHIELD

67

213 262 R1

SNAP RING, PLUNGER ASM

68

213 262 R1

SNAP RING - SHIFT LEVER SHAFT

69

1307 322 H1

WICK, OIL RESERVOIR - CE

70

1302 333 H1

WICK, OIL RESERVOIR - DE

71

1307 323 H1

WICK, OIL RESERVOIR - LEVER HSG

|$75

ONLY. ORDER TH

E SERVICE STARTING MOTOR
