ГЕНЕРАТОР 7 AMP - VOLT

Запчасти Komatsu PC400LC-6LC ГЕНЕРАТОР 7 AMP - VOLT ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LC - ГЕНЕРАТОР 7 AMP - VOLT ДВИГАТЕЛЬ
34
32
28
9
15
23
19
16
27
29
4
10
11
18
2
7
1
26
24
8
3
6
17
5
21
33
22
25
31
30
13
14
12
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

6732-81-6110

ALTERNATOR 70A-24V

|$1

1305 787 H91

ALTERNATOR 70A-24V

1

1307 574 H1

FRAME SRE

2

389 603 C91

BEARING

3

1307 575 H1

ROTOR ASSY

4

1307 326 H1

STATOR ASSY

5

1307 327 H1

FRAME DE

6

1213 268 H1

BEARING

7

1307 328 H1

RECTIFIER BRIDGE ASSY

8

1307 329 H1

DIODE TRIO

9

1218 115 H1

REGULATOR

10

1307 330 H1

TERMINAL PKG - OUTPUT

11

1307 331 H1

TERMINAL PKG - RELAY

12

1307 332 H1

CONNECTOR REGULATOR STUD

13

1307 333 H1

CONNECTOR RELAY TERMINAL

14

1307 334 H1

CAPACITOR

15

1307 335 H1

BRUSH HOLDER ASSY

16

1307 336 H1

BRUSH & ARM

17

1307 337 H1

RETAINER PLATE DE

18

1213 242 H1

BUSHING

19

1218 130 H1

COVER

21

1307 576 H1

FAN

22

NSS

PULLEY

23

1218 126 H1

NUT ASSY

24

120 622

NUT-HEX MACH, 8-32 ZND 1

25

1307 577 H1

NUT, SHAFT DE

26

1268 365 H1

SCREW & WASHER ASSY

27

1236 654 H1

SCREW & WASHER ASSY

28

1268 365 H1

SCREW & WASHER ASSY

29

1216 375 H1

SCREW (8-32 UNC)

30

1307 339 H1

SCREW, CAPACITOR ATCH

31

1268 363 H1

SCREW

32

1307 578 H1

SCREW & LOCK WASHER

33

1268 370 H1

WASHER

34

1307 341 H1

THRU BOLT

N/I

1307 342 H1

CONNECTOR PKG - REGULATOR TO INDICATOR LIGHT

N/I

1307 331 H1

CONNECTOR PKG - INDICATOR LIGHT
