Запчасти Komatsu PC400LC-6LC ПРИВОД ВЕНТИЛЯТОРА ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LC - ПРИВОД ВЕНТИЛЯТОРА ДВИГАТЕЛЬ
25
24
12
17
19
23
20
10
22
18
26
11
9
21
16
5
15
1
7
8
6
2
3
4
14
13

Артикул

Название

Примечание

Количество

|$0

1304 974 H91

ASSEMBLY, FAN HUB

1

1240 450 H1

SHAFT, FAN HUB

2

1304 975 H1

FLANGE

3

1246 268 H1

WASHER, PLAIN (M10)

4

1294 005 H1

BOLT (M10x1.50x25)

5

1268 118 H1

COVER, FAN HUB

6

1304 778 H1

BEARING, ROLLER

7

1246 267 H1

SEAL, OIL

8

1240 469 H1

HUB, FAN

9

1246 160 H1

BOLT (M10x1.50x30)

10

1295 206 H1

SUPPORT, FAN

11

1246 561 H2

BOLT (M10x1.50x90)

12

1295 207 H1

BOLT (M10x1.50x145)

13

1295 330 H1

PULLEY, FAN

14

1304 728 H1

BELT, FAN DRIVE

|$15

1304 665 H1

ASSEMBLY, IDLER PULLEY

15

1268 113 H1

COVER, IDLER PULLEY

16

1268 114 H1

O-RING

|$18

1304 779 H1

PULLEY, IDLER

17

1296 106 H1

SHAFT, IDLER

18

1294 005 H1

BOLT (M10x1.50x25)

19

1246 280 H1

SEAL, OIL

20

1304 780 H1

PULLEY, IDLER

21

1246 276 H1

WASHER, PLAIN (M10.5.)

22

1246 277 H1

BEARING, ROLLER

23

1246 284 H1

NUT, REG HEX (M20x1.50)

24

1246 285 H1

WASHER, PLAIN (7/8 IN)

25

1246 272 H1

PIN, ROLL

26

6735-71-5670

WASHER, PLAIN

Выбрано товаров: 29
