Запчасти Komatsu PC400LC-6LC ТОПЛИВН. ОТСЕКАЮЩ. КЛАПАН ДВИГАТЕЛЬ

|$0

1239 688 H92

VALVE, SHUTOFF

1

1250 284 H1

SOLENOID

|$2

1238 258 H91

BODY, SHUTOFF VALVE

2

1238 255 H1

BODY, SHUTOFF VALVE

3

1238 256 H1

KNOB

4

1294 098 H1

O-RING

5

1238 976 H1

SHAFT, SHUTOFF VALVE

6

117 737

SHIELD, SHUTOFF VALVE

7

117 741

SPRING, VALVE

8

117 738

SEAL, RECTANGULAR RING

9

1238 507 H1

SCREW (3/16 - 24 5/8 INCH)

10

1239 609 H1

DISC, VALVE

11

6216-14-4810

PLUG, PIPE (1/8 NPT)

12

1294 481 H1

BOLT (1/4 - 20x1 3/4 INCH)

13

1238 480 H1

WASHER, LOCK (1/4 INCH)

14

117 740

SEAL, RECTANGULAR RING

15

1240 005 H1

WASHER, PLAIN (1/4 INCH)
