Запчасти Komatsu PC400LC-6LC FIG NO. K-A НАВЕСНОЕ ОБОРУД-Е PPC АКТУАТОР КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-62-23410

HOSE, 1950 MM

2

20Y-62-23570

HOSE, 1900 MM

3

20Y-62-22810

BAND, YELLOW

4

20Y-62-22170

CLAMP

5

20Y-62-22180

CLAMP

6

01010-51016

BOLT

7

01643-31032

WASHER

8

08034-00536

BAND

9

203-62-58470

CLIP

10

01010-51225

BOLT

11

01643-31032

WASHER

12

20Y-62-22880

HOSE, 980 MM

13

20Y-62-23370

HOSE, 1200 MM

14

20Y-62-25550

HOSE, 2150 MM

15

20Y-62-25560

HOSE, 2200 MM

16

20Y-62-22170

CLAMP

17

20Y-62-22860

BAND, BROWN

18

20Y-62-22790

BAND, RED

19

20Y-62-22840

BAND, BLACK

20

20Y-62-22820

BAND, BLUE

21

20Y-62-22180

CLAMP

22

01010-51016

BOLT

23

01643-31032

WASHER

24

08034-00536

BAND

25

20Y-62-22220

BLOCK

26

01011-51010

BOLT

27

01643-31032

WASHER

28

08053-01512

CLIP

29

20Y-62-16630

NIPPLE

30

201-60-11390

O-RING

31

20Y-62-19560

O-RING

32

07002-01423

O-RING

33

20Y-06-21710

SWITCH

34

20Y-06-22430

HARNESS, WIRING
