Запчасти Komatsu PC400LC-6LC FIG NO. K-A РЫЧАН УПРАВЛ-Я ХОДОМ PPC КЛАПАН КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

702-16-01220

VALVE ASSEMBLY, PILOT

1

NSS

BODY

2

NSS

PLUG

3

NSS

VALVE

4

702-16-51140

SHIM, 0.3MM

5

702-16-53420

SPRING

6

702-16-53140

RETAINER

7

702-16-54420

SPRING

8

702-16-53170

PISTON

9

702-16-51270

SEAL

10

702-16-54170

COLLAR

11

07000-02020

O-RING

12

702-16-54460

PLATE

13

702-16-54121

LEVER

14

702-16-54280

SEAL

15

702-16-54430

BUSHING

16

04025-00432

PIN

17

702-16-54310

CASE

18

01010-50855

BOLT

19

01643-30823

WASHER

20

01010-50816

BOLT

21

702-16-54351

SHIM, 1.0MM

|$22

702-16-54341

SHIM, 1.3MM

|$23

702-16-54331

SHIM, 1.6MM

22

702-16-54450

SHAFT

23

01252-30525

BOLT

24

702-16-54510

PLATE

25

04025-00420

PIN

26

702-16-54520

LEVER

27

702-16-54530

PIN

28

01224-40612

SCREW

|$31

702-16-54500

DAMPER ASSEMBLY

29

NSS

CASE

30

NSS

PISTON

31

NSS

O-RING

32

NSS

WASHER

33

NSS

RING

34

NSS

PLUG
