Запчасти Komatsu PC400LC-6LC FIG NO. K7-A ПЕЧКА И КОНДИЦ. ВОЗДУХА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-979-A210

AIR CONDITIONER ASSEMBLY

1

20Y-977-A470

WELDMENT, HOUSING

2

20Y-977-A640

COIL, HEATER

3

20Y-977-A820

BLOWER, ASSEMBLY

4

20Y-977-A540

COVER, RECIRCULATING FILTER

5

20Y-977-A310

COVER, HOUSING

6

20Y-977-A410

FOAM, COVER, TOP

7

20Y-977-A420

FOAM, RECIRCULATING FILTER

8

20Y-977-A380

SHIELD, HEAT, RESISTER

9

20Y-977-A610

RIVET, PLASTIC

10

20Y-977-A590

SCREW, CAP 5 X 20 MM

11

120 217

WASHER, LOCK

12

425-963-A850

BOLT, 10-32 X 1/2 IN

13

425-963-A860

BOLT, 1/4-20 X 1/2 IN

14

20Y-977-A630

KNOB, RECIRCULATING FILTER

15

20Y-977-A580

BOLT, 5/16-18 X 3/4 IN

16

20Y-977-A740

RESISTOR

17

20Y-977-A440

FOAM, DRAIN

18

20Y-977-A370

BRACKET, FILTER, AIR INTAKE

19

20Y-977-A550

DOOR, AIR INTAKE

20

425-963-A820

TIE, NYLON

21

20Y-977-A780

HARNESS, WIRING

22

20Y-977-A490

BRACKET, EVAPORATOR

23

20Y-977-A510

BRACKET, HOUSING

24

20Y-977-A520

BRACKET, FAN, SIDE MOUNTING

25

20Y-977-A560

BRACKET, FAN, TOP MOUNTING

26

20Y-977-A620

BOLT, 5/16-18 X 3/8 IN

|$28

20Y-977-A060

VALVE ASSEMBLY, WATER

28

20Y-977-A650

VALVE, WATER

29

LA 1049

HOSE, HEATER (3 1/4 IN LONG)

30

20Y-977-A120

CLAMP, HOSE

31

20Y-977-A720

TUBE

32

20Y-977-A120

CLAMP, HOSE

33

299 410 C1

CLIP, HOSE

34

20Y-977-A880

BRACKET, WATER VALVE

35

20Y-979-A810

BLOCK, SPACER

36

20Y-979-A820

BRACKET, BLOCK VALVE

37

20Y-979-A830

SCREW, LOCK

38

20Y-979-A840

SCREW, 1/4 X 3/4 IN

39

425-963-A960

SWITCH, LOW PRESSURE

40

20Y-979-A850

ADAPTER, 3 IN HOSE

41

425-963-AB60

O-RING

42

416-963-A270

BLOCK, VALVE

43

20Y-979-A860

DUCT, EXHAUST

44

20Y-979-A870

COIL, EVAPORATOR

45

20Y-979-A880

THERMOSTAT

46

20Y-979-A890

ASSEMBLY, HOSE, DRAIN

47

EF 3512

WASHER, LOCK
