Запчасти Komatsu PC400LC-6LC КОЛЕНВАЛ ESN 8877 И DOWN ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LC - КОЛЕНВАЛ ESN 8877 И DOWN ДВИГАТЕЛЬ
4
1
6
2
3
5
8
7

Артикул

Название

Примечание

Количество

1

1304 956 H1

CRANKSHAFT, ENGINE

2

1246 143 H1

KEY, PLAIN WOODRUFF

3

1304 957 H1

GEAR, CRANKSHAFT

4

1240 556 H1

SLEEVE, WEAR (REAR)

5

1296 127 H1

SLEEVE, WEAR (FRONT)

|$5

1246 138 H91

SET, MAIN BEARING - STANDARD

6

1246 139 H1

BEARING, MAIN - UPPER

7

1246 140 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$9

1240 512 H91

SET, MAIN BEARING - .010 IN OVERSIZE

6

1240 434 H1

BEARING, MAIN - UPPER

7

1240 438 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$13

1240 513 H91

SET, MAIN BEARING - .020 IN OVERSIZE

6

1240 435 H1

BEARING, MAIN - UPPER

7

1240 439 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$17

1240 514 H91

SET, MAIN BEARING - .030 IN OVERSIZE

6

1240 436 H1

BEARING, MAIN - UPPER

7

1240 440 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$21

1240 515 H91

SET, MAIN BEARING - .040 IN OVERSIZE

6

1240 437 H1

BEARING, MAIN - UPPER

7

1240 441 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

8

1240 479 H1

BEARING, THRUST - .010 IN OVERSIZE

Выбрано товаров: 26
