Запчасти Komatsu PC400LC-6LC FIG NO. H8-A СОЛЕНОИДНЫЙ КЛАПАН ГИДРАВЛИКА

|$0

20Y-60-A1310

VALVE ASSEMBLY

1

20Y-60-A1360

VALVE ASSEMBLY, SOLENOID

|$2

20Y-60-A1320

VALVE, SOLENOID

|$3

RK0217

SEAL KIT

2

20Y-60-A1340

COIL ASSEMBLY

|$5

08055-00282

CONNECTOR

|$6

08023-06041

COVER

3

20Y-60-A1330

MANIFOLD

4

20Y-60-22140

VALVE, CHECK

|$9

RK0259

SEAL KIT

|$10

VE4080

PLUG

|$11

VE3841

PLUG

5

205-62-55270

NIPPLE

6

07002-01423

O-RING

7

07235-10315

ELBOW

8

07002-02034

O-RING

9

20Y-62-22330

ELBOW

10

07002-02034

O-RING

11

01010-81005

BOLT

12

01643-31032

WASHER

13

20Y-62-A1210

ACCUMULATOR

14

203-62-65281

ELBOW

15

07002-02034

O-RING

16

07283-23450

CLIP

17

01599-01011

NUT

18

01643-31032

WASHER

19

20Y-62-17380

HOSE

|$27

48A-62-13390

HOSE

20

20Y-62-23230

HOSE

21

20Y-62-22980

HOSE, 600 MM

22

207-62-62810

HOSE ASSEMBLY

23

07102-20319

HOSE

24

07102-20320

HOSE

25

07102-20321

HOSE

26

20Y-62-22790

BAND, RED

27

20Y-62-22810

BAND, YELLOW

28

08034-00519

BAND

29

04434-51812

CLIP

30

01010-51225

BOLT

31

01643-31232

WASHER

32

208-06-19170

CLIP

33

01010-51230

BOLT

34

01643-31232

WASHER
