Запчасти Komatsu PC400LC-6LC FIG NO. H-A ОСНОВН. НАСОС (/9) С IMPELLER НАСОС ГИДРАВЛИКА

1

708-2H-22120

SHAFT, REAR

2

708-1H-12151

BEARING

3

708-17-05010

WASHER KIT

|$5

NSS

WASHER, 3.0MM

|$6

NSS

WASHER, 3.1MM

|$7

NSS

WASHER, 3.2MM

4

708-17-12780

RING, SNAP

|$9

708-2H-04150

BLOCK ASSEMBLY, CYLINDER

5

708-2H-23160

BLOCK, CYLINDER

6

708-2H-23240

PLATE, VALVE

7

708-2H-23350

RETAINER

8

708-2H-23151

SPRING

9

708-2H-23130

SEAT

10

708-2H-13141

SEAT

11

04065-05820

RING

12

708-2H-23360

PIN

13

708-2H-23340

RETAINER, SHOE

14

708-2H-23311

PISTON SUB ASSEMBLY

|$20

708-2H-04160

CRADLE ASSEMBLY

15

708-2H-23850

CRADLE

16

708-2H-23450

CAM, ROCKER

17

04020-01434

PIN

18

706-75-40340

BOLT

19

07000-B1009

O-RING
