Запчасти Komatsu PC400LC-6LC FIG NO. H-A ОСНОВН. НАСОС (/9) С IMPELLER НАСОС ГИДРАВЛИКА

1

708-2H-22110

SHAFT

2

708-1H-12151

BEARING

3

708-17-05010

WASHER KIT

|$5

NSS

WASHER, 3.0MM

|$6

NSS

WASHER, 3.1MM

|$7

NSS

WASHER, 3.2MM

4

708-17-12780

RING, SNAP

5

708-27-22810

SEAL

6

708-2H-22160

SPACER

7

04065-08225

RING

|$12

708-2H-04140

CYLINDER BLOCK A

8

708-2H-23160

BLOCK, CYLINDER

9

708-2H-23230

PLATE, VALVE

10

708-2H-23350

RETAINER, GUIDE

11

708-2H-23151

SPRING

12

708-2H-23130

SEAT

13

708-2H-23141

SEAT

14

04065-05820

RING

15

708-2H-23360

PIN

16

708-2H-23340

RETAINER, SHOE

17

708-2H-23311

PISTON SUB ASSEMBLY

|$23

708-2H-04160

CRADLE ASSEMBLY

18

708-2H-23850

CRADLE

19

708-2H-23450

CAM, ROCKER

20

04020-01434

PIN

21

706-75-40340

BOLT

22

07000-B1009

O-RING
