Запчасти Komatsu PC400LC-6LC FIG NO. H-A ОСНОВН. КЛАПАН АКТУАТОР (/) ГИДРАВЛИКА

|$2

723-40-66300

VALVE ASSEMBLY

1

NSS

CASE

2

NSS

SEAT

3

NSS

SEAT

4

NSS

BALL

5

NSS

PLUG

|$8

709-70-74700

VALVE ASSEMBLY, SUCTION AND SAFETY

6

NSS

SLEEVE

7

NSS

SLEEVE

8

NSS

POPPET

9

NSS

PISTON

10

NSS

PLUG

11

NSS

POPPET

12

NSS

SCREW

13

NSS

SPRING

14

NSS

SPRING

15

NSS

SPRING

16

NSS

SEAL

17

NSS

SEAL

18

709-25-11390

O-RING

19

NSS

O-RING

20

NSS

O-RING

21

NSS

NUT

|$25

723-46-48100

VALVE ASSEMBLY

22

NSS

SLEEVE

23

NSS

VALVE

24

NSS

SEAT

25

NSS

POPPET

26

NSS

PLUG

27

NSS

SCREW

28

NSS

NUT

29

NSS

NUT

30

NSS

SPRING

31

NSS

SPRING

32

NSS

PLATE

33

NSS

CAP

34

NSS

SEAL

35

NSS

SEAL

36

700-93-11320

O-RING

37

723-46-41950

RING

38

07002-13634

O-RING

39

NSS

O-RING

40

NSS

RING

41

NSS

O-RING

42

NSS

RING, BACK-UP
