Запчасти Komatsu PC400LC-6LC БЛОК ЦИЛИНДРОВ С ДРЕНАЖ COVER ДВИГАТЕЛЬ

|$0

1295 191 H92

BLOCK ASSEMBLY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

1246 122 H1

DOWEL, PIN - No. 4 only

3

1238 448 H1

PLUG, RETAINER

4

1239 318 H1

WASHER, PLAIN

5

1239 319 H1

DISC, VALVE

6

1239 320 H1

SPRING, BYPASS VALVE

7

1294 031 H1

BUSHING, CAMSHAFT

8

6732-61-2240

PLUG, PIPE - (1/4 NPT)

9

1246 121 H1

SEAT, PRESSURE REG VALVE

|$10

1246 125 H91

KIT, MAIN BEARING CAP - No. 4 only

10

NSS

CAP, MAIN BEARING - No. 4 only

11

1246 127 H1

PIN, ROLL

10

1246 128 H1

CAP, MAIN BEARING - No. 1,2,3,5,6,7

|$14

1295 682 H91

KIT, BOLT

12

NSS

BOLT (M14x1.50x160)

13

1246 124 H1

WASHER, PLAIN

14

1240 051 H1

DOWEL, PIN (5/16x1/2 IN)

15

1246 112 H1

DOWEL, PIN (7/16x1 IN)

16

6736-21-1820

PLUG, EXPANSION (1.00 IN)

17

1239 144 H1

PLUG, EXPANSION (.387mm)

18

1246 114 H1

DOWEL, PIN (6.00x12.00mm)

19

6732-11-1910

PLUG, PIPE (1/2 NPT)

20

1246 116 H1

DOWEL, RING (19.23mm)

|$24

1246 118 H91

PLUG, THREADED (9/16 - 18 IN)

21

NSS

PLUG, THREADED

22

1246 119 H1

O-RING

|$27

1246 131 H91

PLUG, THREADED (3/4-16 IN)

23

NSS

PLUG, THREADED

24

6735-21-4160

O-RING

25

1296 124 H1

SENSOR, VISCOSITY

26

1246 117 H2

STUD (M10x1.50x50mm)

27

1296 126 H1

PLUNGER, PRESSURE REGULATOR

28

1239 195 H1

SPRING, COMPRESSION

29

1246 137 H1

PLUG, RETAINER

30

1310 675 H1

COVER, OIL DRAIN BACK

31

1310 676 H1

SCREW, ROUND HEAD

32

1310 677 H1

SEAL, O-RING

33

1310 678 H1

CLIP

34

1310 679 H1

NUT, HEX FLANGE
