Запчасти Komatsu PC400LC-6LC FIG NO. H-AA ОСНОВН. КЛАПАН - АКТУАТОР (/) PCLC/HD- - заводской номер A888 И UP ГИДРАВЛИКА

|$0

723-48-17102

CONTROL VALVE ASSEMBLY

|$1

723-46-00610

COVER ASSEMBLY

1

NSS

COVER

2

NSS

PLUG

|$4

723-46-00620

COVER ASSEMBLY

3

NSS

COVER

4

NSS

PLUG

5

NSS

PLUG

6

723-40-70200

VALVE ASSEMBLY

7

723-46-15460

PLATE

8

723-40-66100

VALVE ASSEMBLY

9

723-40-66200

VALVE ASSEMBLY

10

07000-12012

O-RING

11

07000-12015

O-RING

12

07000-12018

O-RING

13

07000-12021

O-RING

14

07000-13025

O-RING

15

07000-13028

O-RING

16

07000-13032

O-RING

17

07000-03040

O-RING

18

01010-51490

BOLT

19

01010-51460

BOLT

20

01643-31445

WASHER

21

01010-51040

BOLT

22

01643-31032

WASHER

23

01252-31050

BOLT

24

01643-51032

WASHER

25

723-46-15220

BOLT

26

723-46-11910

BLOCK

27

723-46-15510

O-RING

28

01252-30865

BOLT

29

709-90-71100

VALVE ASSEMBLY, SUCTION AND SAFETY
