Запчасти Komatsu PC400LC-6LC ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

1

1246 488 H2

GASKET, TURBOCHARGER

|$1

1307 643 H91

TURBOCHARGER

2

1246 461 H1

PLATE, CLAMPING

3

1241 624 H1

SLINGER, OIL NG

4

1246 468 H1

BEARING, TURBOCHARGER

5

6736-81-8530

WASHER, LOCK (M6)

6

6736-81-8480

SCREW

7

1307 077 H1

HOUSING, TURBINE

8

1294 189 H1

PLATE, CLAMPING

9

1240 507 H1

BOLT (M6x1.00x12)

10

1307 078 H1

HOUSING, COMPRESSOR

11

6736-81-8470

DATAPLATE

12

1296 003 H1

BAFFLE, OIL

13

1296 004 H1

PLATE, OIL SEAL

14

1307 079 H1

SHAFT AND WHEEL

15

1307 080 H1

COLLAR, THRUST

16

1296 842 H1

BEARING, THRUST

17

1304 758 H1

SHIELD, HEAT

18

1307 081 H1

IMPELLER, COMPRESSOR

19

6733-81-8480

PIN, ROLL

20

1307 083 H1

HOUSING, BEARING

21

1246 477 H1

RING, RETAINING

22

6216-84-8420

RING, RETAINING

23

6736-81-8440

SEAL, SPLIT RING

24

6736-81-8320

SEAL, SPLIT RING

25

6736-81-8380

BOLT (M8x1.25x12)

26

1246 482 H1

NUT, LOCK (M8x1.25)

27

1294 190 H1

O-RING

28

6732-81-8810

STUD

29

6732-81-8820

NUT (M10x1.50)

30

1294 490 H1

GASKET, TURBOCHARGER

31

6732-81-8830

GASKET, TURBOCHARGER
