Артикул
Название
Примечание
Количество
|1
723-48-19600
CONTROL VALVE
|1
723-48-19303
CONTROL VALVE
|1
723-48-19302
CONTROL VALVE
|1
723-48-19301
CONTROL VALVE
|1
723-48-19300
CONTROL VALVE
|1
723-48-17300
CONTROL VALVE
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-41A0 TO Y1664-54A0.
|1
BODY SUB ASS'Y
1
723-46-41110
VALVE
|2
723-46-45100
VALVE ASS'Y
2
SLEEVE
3
PISTON SUB ASS'Y
4
SPRING
5
SEAL
6
700-93-11320
O-RING
7
723-46-41950
RING
8
07002-13634
O-RING
9
01252-60845
BOLT
10
01643-50823
WASHER
|11
723-40-66300
VALVE ASS'Y
11
CASE
12
SEAT
13
SEAT
14
BALL
15
PLUG
|16
709-70-74600
VALVE ASS'Y,SUCTION AND SAFETY
16
SLEEVE
17
SLEEVE
18
POPPET
19
PISTON
20
PLUG
21
POPPET
22
SCREW
23
SPRING
24
SPRING
25
SPRING
26
SEAL
27
SEAL
28
709-25-11390
O-RING
29
O-RING
30
O-RING
31
NUT
|32
709-70-74203
VALVE ASS'Y,SUCTION AND SAFETY
32
SLEEVE
33
SLEEVE
34
POPPET
35
PISTON
36
PLUG
37
POPPET
38
SCREW
39
SPRING
40
SPRING
41
SPRING
42
SEAL
43
SEAL
44
709-25-11390
O-RING
45
O-RING
46
O-RING
47
NUT
Выбрано товаров: 59
