Запчасти Komatsu PC400LC-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (8/) (ДЛЯ ПОГРУЗ.) (С ПРЕДОТВРАЩ. СМЕЩЕНИЯ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-19600

CONTROL VALVE

|1

723-48-19303

CONTROL VALVE

|1

723-48-19302

CONTROL VALVE

|1

723-48-19301

CONTROL VALVE

|1

723-48-19300

CONTROL VALVE

|1

723-48-17300

CONTROL VALVE

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-41A0 TO Y1664-54A0.

|1

709-70-74203

VALVE ASS'Y,SUCTION AND SAFETY

1

SLEEVE

2

SLEEVE

3

POPPET

4

PISTON

5

PLUG

6

POPPET

7

SCREW

8

SPRING

9

SPRING

10

SPRING

11

SEAL

12

SEAL

13

709-25-11390

O-RING

14

O-RING

15

O-RING

16

NUT

|17

709-70-75900

VALVE ASS'Y,SUCTION AND SAFETY

17

SLEEVE

18

SLEEVE

19

POPPET

20

PISTON

21

PLUG

22

POPPET

23

SCREW

24

SPRING

25

SPRING

26

SPRING

27

SEAL

28

SEAL

29

709-25-11390

O-RING

30

O-RING

31

O-RING

32

NUT

|33

723-40-90101

VALVE ASS'Y,SUCTION AND SAFETY

|33

723-40-90100

VALVE ASS'Y,SUCTION AND SAFETY

33

SLEEVE

34

SLEEVE

35

POPPET

36

PISTON

|36

PISTON

37

SLEEVE

38

POPPET

39

UNION

40

PISTON

41

SPRING

42

SPRING

43

SPRING

44

SEAL

45

SEAL

46

709-25-11390

O-RING

47

O-RING

|47

O-RING

48

NUT

49

NUT

50

HOLDER

51

O-RING

|51

O-RING

52

SPRING

53

SEAL

|54

723-40-85100

VALVE ASS'Y,SUCTION

54

SLEEVE

55

VALVE

56

SPRING

57

SEAL

58

709-25-11390

O-RING
