Артикул
Название
Примечание
Количество
|1
723-47-19401
CONTROL VALVE
|1
723-47-19400
CONTROL VALVE
|1
723-47-19102
CONTROL VALVE
|1
723-47-19101
CONTROL VALVE
|1
723-47-19100
CONTROL VALVE
|1
723-47-17103
CONTROL VALVE
|1
723-47-17102
CONTROL VALVE
|1
723-47-17101
CONTROL VALVE
|$$9
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-12A0.
|1
723-40-66100
VALVE ASS'Y
1
CASE
2
SEAT
3
708-8E-16160
PLUG
4
07002-11023
O-RING
5
SEAT
6
BALL
7
PLUG
|8
723-40-66200
VALVE ASS'Y
8
CASE
9
SEAT
10
SEAT
11
BALL
12
PLUG
13
01252-61050
BOLT
14
01643-51032
WASHER
|15
723-40-60101
VALVE ASS'Y
|15
723-40-60100
VALVE ASS'Y
15
SLEEVE
16
VALVE
17
PISTON
|17
PISTON
18
PISTON
19
SPRING
20
07000-12020
O-RING
21
07001-02020
RING,BACK-UP
22
709-25-11390
O-RING
23
SPRING
24
PLUG
25
O-RING
26
SEAL
|26
SEAL
27
O-RING
Выбрано товаров: 42
