Артикул
Название
Примечание
Количество
|1
723-47-17103
CONTROL VALVE
|1
723-47-17102
CONTROL VALVE
|1
723-47-17101
CONTROL VALVE
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-12A0.
|1
BODY SUB ASS'Y
|1
BODY SUB ASS'Y
1
BLOCK,VALVE
2
SPOOL
3
SPOOL
4
SPOOL
|4
SPOOL
5
SPOOL
6
SPOOL
7
723-46-15130
PLUG
8
723-46-15140
PLUG
9
07002-10823
O-RING
10
708-7T-16460
BALL
11
723-46-15120
RETAINER
12
723-46-15260
RETAINER
13
723-46-14110
SPRING
14
723-46-14170
SPRING
15
723-46-14131
SPRING
16
723-46-15110
CASE
17
07430-71380
O-RING
18
01252-30820
BOLT
19
723-46-15410
CASE
20
723-46-15420
RETAINER
21
723-46-15450
PLUG
22
07002-03034
O-RING
23
723-46-15440
SPRING
24
723-46-15430
PISTON
25
PLUG
26
723-46-15150
VALVE
27
723-46-14150
SPRING
Выбрано товаров: 34
