Артикул
Название
Примечание
Количество
|1
706-88-00151
MOTOR ASS'Y
|1
706-88-00150
MOTOR ASS'Y
|1
706-88-00112
MOTOR ASS'Y
|1
706-88-00111
MOTOR ASS'Y
|1
706-88-00110
MOTOR ASS'Y
|$$6
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1641-01A0 TO Y1641-03A0.
1
706-88-40370
O-RING
2
07000-12012
O-RING
3
706-88-40310
BOLT
4
706-88-40660
SHAFT,DRIVE
5
706-88-40880
BEARING
6
706-88-40890
BEARING
7
706-88-40810
RETAINER
8
706-88-05010
SPACER KIT
|8
SPACER¤ 1.6MM
|8
SPACER¤ 1.7MM
|8
SPACER¤ 1.8MM
9
04064-07525
RING,SNAP
10
708-8K-12141
SEAL,OIL
11
706-88-40710
HOUSING
12
07000-02135
O-RING
13
04071-00140
RING,SNAP
14
706-88-40090
BLOCK,CYLINDER
15
706-88-40080
SHAFT,CENTER
16
706-88-40130
RING,CENTER
17
706-88-40060
SPRING
|18
706-88-05020
RETAINER KIT
18
RETAINER
19
SCREW
20
706-88-40162
PISTON SUB ASS'Y
|20
706-88-40160
PISTON SUB ASS'Y
|20
706-88-40161
PISTON SUB ASS'Y
21
706-88-90140
PLATE
22
706-88-90150
DISC
23
706-88-90180
PISTON,BRAKE
24
07000-15240
O-RING
25
706-88-90130
RING,BACK-UP
26
07000-15270
O-RING
27
07001-05270
RING,BACK-UP
28
706-88-90410
SPRING
Выбрано товаров: 40
