Артикул
Название
Примечание
Количество
|1
706-77-01370
MOTOR ASS'Y
|1
706-77-01301
MOTOR ASS'Y
|1
706-77-01180
MOTOR ASS'Y
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 AND Y1640-02A0.
|1
702-77-04401
VALVE ASS'Y,RELIEF
|1
702-77-04800
VALVE ASS'Y,RELIEF
1
SLEEVE
2
VALVE
3
SEAL
4
SEAL
5
SPRING
6
SPRING
7
SCREW
8
O-RING
9
RING,BACK-UP
10
NUT
11
706-77-72540
SPRING
12
706-77-72520
COVER
13
07000-13042
O-RING
14
01010-81275
BOLT
15
01643-31232
WASHER
|16
702-15-75000
VALVE ASS'Y
16
BODY
17
SPOOL
18
SEAL
19
SPRING
20
PLUG
21
O-RING
22
07000-13042
O-RING
23
07000-11007
O-RING
24
01252-60825
BOLT
Выбрано товаров: 31
