Запчасти Komatsu PC400LC-6 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-77-01370

MOTOR ASS'Y

|1

706-77-01301

MOTOR ASS'Y

|1

706-77-01180

MOTOR ASS'Y

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 AND Y1640-02A0.

|1

706-77-03130

MOTOR SUB ASS'Y

|1

706-77-03070

MOTOR SUB ASS'Y

1

706-77-43210

CASE,MOTOR

2

706-77-72610

HOUSING

|2

706-77-72510

HOUSING

3

706-75-42830

PIN,DOWEL

4

706-77-72170

PLUG

5

07002-12434

O-RING

5A

706-73-71450

PLUG

5B

07002-11423

O-RING

6

706-7G-40010

BEARING

7

706-7E-11440

O-RING

8

706-77-43180

BOLT

9

706-77-43860

SHAFT

10

706-77-43880

BEARING

11

706-77-42890

BEARING

12

706-77-42051

SPRING

13

706-77-42041

SEAT

14

706-77-05010

SPACER KIT

|14

SPACER¤ 2.3MM

|14

SPACER¤ 2.5MM

|14

SPACER¤ 2.7MM

15

04064-06525

RING,SNAP

16

706-77-43950

SEAL,OIL

17

706-77-43060

COVER

18

07000-02125

O-RING

19

04071-00130

RING,SNAP

20

706-77-43191

BLOCK,CYLINDER

21

706-77-43840

PLATE,VALVE

22

708-18-13230

PIN

23

706-77-43080

SHAFT,CENTER

24

706-77-42130

RING,CENTER

25

706-77-42110

SPRING

|26

706-77-05050

RETAINER KIT

26

RETAINER

27

SCREW

28

706-77-42160

PISTON SUB ASS'Y

29

706-77-91540

PLATE

30

706-77-91550

DISC

31

706-77-91580

PISTON,BRAKE

32

07000-15180

O-RING

33

708-8H-15220

O-RING

34

706-77-91510

SPRING
