Запчасти Komatsu PC400LC-6 ОСНОВН. НАСОС (/) (ДЛЯ СНГ)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2H-00350

PUMP ASS'Y

|1

708-2H-00150

PUMP ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-21A0 TO Y1600-33A0.

|1

708-2H-01150

PUMP SUB ASS'Y

|1

708-2H-04160

CRADLE ASS'Y

1

CRADLE

2

CAM,ROCKER

3

04020-01434

PIN

4

07000-51009

O-RING

5

706-75-40340

BOLT

6

708-2H-24311

PISTON

7

708-2H-24220

ROD

8

04020-00514

PIN

9

708-2H-25870

CAM

10

01010-80825

BOLT

11

01643-30823

WASHER

12

708-2H-24260

STOPPER

13

07000-53032

O-RING

14

07001-03032

RING

15

708-2H-24320

SCREW

16

01643-32460

WASHER

17

01583-52414

NUT

18

708-2H-24270

SCREW

19

07002-52434

O-RING

20

708-2H-24140

SPRING

21

708-2H-24130

PLUG

22

07002-53634

O-RING

23

708-2H-24330

PLATE

24

708-2H-24340

PACKING

25

708-23-12350

SCREW
