Артикул
Название
Примечание
Количество
|1
708-2H-00120
PUMP ASS'Y
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-09A0.
|1
708-2H-01121
PUMP SUB ASS'Y
1
708-2H-22110
SHAFT,FRONT
2
708-1H-22150
BEARING
3
708-17-05010
WASHER KIT
|3
WASHER¤ 3.0MM
|3
WASHER¤ 3.1MM
|3
WASHER¤ 3.2MM
4
708-17-12780
RING
5
708-27-22811
SEAL,OIL
6
708-2H-22160
SPACER
7
04065-08225
RING,SNAP
|8
708-2H-04140
CYLINDER BLOCK ASS'Y
8
BLOCK,CYLINDER
9
PLATE,VALVE
10
708-2H-23350
GUIDE,RETAINER
11
708-2H-23151
SPRING
12
708-2H-23130
SEAT
13
708-2H-23141
SEAT
14
04065-05820
RING
15
708-2H-23360
PIN
16
708-2H-23340
RETAINER,SHOE
17
708-2H-23311
PISTON SUB ASS'Y
|18
708-2H-04160
CRADLE ASS'Y
18
CRADLE
19
CAM,ROCKER
20
04020-01434
PIN
21
706-75-40340
BOLT
22
07000-B1009
O-RING
Выбрано товаров: 30
