Запчасти Komatsu PC400LC-6 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ)(№88-) СИСТЕМА ОХЛАЖДЕНИЯ

1

208-03-61350

RADIATOR CORE ASS'Y

1

208-03-68350

RADIATOR CORE ASS'Y

2

20Y-03-22110

CAP

3

205-03-62660

PLUG

4

07000-11007

O-RING

5

205-03-71230

HOSE

6

20Y-03-11330

CLIP

7

01010-81225

BOLT

8

01643-31232

WASHER

9

208-03-64110

OIL COOLER

10

01010-81225

BOLT

11

01643-31232

WASHER

12

01010-81225

BOLT

13

01643-31232

WASHER

14

207-03-51171

SEAL

15

207-03-51181

SEAL

16

208-03-61250

SHEET

17

208-03-61240

SHEET

18

208-03-64250

SHEET

19

208-03-64130

FRAME

20

208-03-64140

FRAME

21

6152-62-5110

AFTERCOOLER ASS'Y

21A

6110-23-6490

SPACER

22

01010-81040

BOLT

22

01010-81030

BOLT

23

01643-31032

WASHER

24

208-03-64150

BRACKET

25

208-03-64161

BRACKET

25

208-03-64160

BRACKET

26

01010-81030

BOLT

27

01643-31032

WASHER

28

208-03-64240

NET

29

01434-10620

BOLT, WING

30

01643-30623

WASHER

31

208-03-64170

SHROUD

32

208-03-61512

GUARD

33

01010-81225

BOLT

34

01643-31232

WASHER

35

208-03-64120

TUBE

36

07283-24949

CLIP

37

01599-01011

NUT

38

01643-31032

WASHER

39

208-03-61221

BRACKET

40

07000-13045

O-RING

41

01010-81240

BOLT

42

01643-51232

WASHER

43

01010-81025

BOLT

44

01643-31032

WASHER

45

208-979-6410

BRACKET

46

01010-80816

BOLT

47

01643-30823

WASHER

48

208-979-6420

BRACKET

49

01010-80816

BOLT

50

01643-30823

WASHER

51

208-979-6430

BRACKET

52

01010-80816

BOLT

53

01643-30823

WASHER
