Запчасти Komatsu PC400LC-5 МЕХАНИЗМ ПОВОРОТА МЕХ-М ОТБОРА МОЩНОСТИ И ПОВОРОТН.
№
Артикул
Название
Примечание
Количество
|$0
208-26-00100
MACHINERY ASSEMBLY, SWING
1
208-26-52242
SHAFT
2
07012-00150
SEAL
3
208-26-52260
COVER
|$4
01010-81040
BOLT
|$5
01643-31032
WASHER
4
06000-22326
BEARING
5
208-26-52251
SPACER
6
208-26-52131
CASE, SWING MACHINERY
|$9
01010-82485
BOLT
|$10
01643-32460
WASHER
|$11
07000-05335
O-RING
7
06000-22224
BEARING
8
208-26-52190
HOLDER
9
208-26-52160
GEAR, PLANETARY
10
208-26-52170
BEARING
11
208-26-52180
PIN
12
01011-51615
BOLT
13
208-26-52220
CARRIER
14
208-26-52230
PLATE
15
205-32-51210
BOLT
16
208-26-52210
GEAR, RING
17
208-26-52122
BASE, SWING MACHINERY
|$23
01010-81615
BOLT
|$24
01643-31645
WASHER
18
208-26-52280
GEAR, SUN
19
06002-32922
BEARING
20
208-26-52152
GEAR
21
04020-01228
PIN, DOWEL
22
07049-01822
PLUG
23
208-26-52111
COVER
|$31
01010-81660
BOLT
|$32
01643-31645
WASHER
|$33
07049-01620
PLUG
24
06002-30213
BEARING
25
208-26-52430
GEAR
26
208-26-52320
CAGE
|$37
01010-81035
BOLT
|$38
01643-31032
WASHER
27
07000-05175
O-RING
28
207-26-00110
SHIM KIT
|$41
207-26-54320
SHIM, 0.016 IN. (0.4 MM)
|$42
207-26-54330
SHIM, 0.020 IN. (0.5 MM)
|$43
207-26-54340
SHIM, 0.024 IN. (0.6 MM)
|$44
207-26-54350
SHIM, 0.028 IN. (0.7 MM)
|$45
207-26-54360
SHIM, 0.031 IN. (0.8 MM)
|$46
207-26-54370
SHIM, 0.016 IN. (0.4 MM)
|$47
207-26-54380
SHIM, 0.020 IN. (0.5 MM)
|$48
207-26-54390
SHIM, 0.024 IN. (0.6 MM)
|$49
207-26-54410
SHIM, 0.028 IN. (0.7 MM)
|$50
207-26-54420
SHIM, 0.031 IN. (0.8 MM)
29
208-26-00120
SHIM KIT
|$52
208-26-52370
SHIM, 0.016 IN. (0.4 MM)
|$53
208-26-52380
SHIM, 0.020 IN. (0.5 MM)
|$54
208-26-52390
SHIM, 0.024 IN. (0.6 MM)
|$55
208-26-52410
SHIM, 0.028 IN. (0.7 MM)
|$56
208-26-52420
SHIM, 0.031 IN. (0.8 MM)
30
07000-05165
O-RING
31
208-26-52310
CAGE
|$59
01010-81035
BOLT
|$60
01643-31032
WASHER
32
07049-01012
PLUG
33
07042-30108
PLUG
Выбрано товаров: 63
