Запчасти Komatsu PC400LC-5 СТАРТЕР (7. KW) ЭЛЕКТРИКА

|$0

600-813-4670

MOTOR, STARTING - 7.5 KW

1

KD7-23100-0290

ARMATURE ASSEMBLY

2

KD1-0456-62047

BEARING, BALL

3

KD0-23230-0150

FIELD COIL ASSEMBLY

4

KD7-23780-0160

TERMINAL ASSEMBLY

5

KD1-23310-0400

FRONT BRACKET ASSEMBLY

6

KD7-23351-0080

METAL

7

KD7-23120-0090

SHAFT ASSEMBLY

8

KD1-0456-60067

BEARING, BALL

9

KD1-23181-0020

STOPPER, PINION

10

KD1-23914-0020

RING, CLIP

11

KD1-23500-0170

CLUTCH ASSEMBLY

12

KD1-23600-0100

CENTER BRACKET ASSEMBLY

13

KD1-23611-0080

BRACKET, CENTER

14

KD1-23320-0190

SHIFT LEVER ASSEMBLY

15

KD0-47100-3420

MAGNETIC SWITCH ASSEMBLY

|$16

KD7-23700-0150

REAR BRACKET ASSEMBLY

16

KD0-23700-0040

REAR BRACKET ASSEMBLY

17

KD7-23351-0060

BUSHING

18

KD1-23913-0040

SPRING, BRUSH

19

KD0-23750-0050

BRUSH HOLDER ASSEMBLY

20

KD1-23740-0050

BRUSH ASSEMBLY

21

KD1-25922-2800

PLATE

22

KD0-23901-0030

BOLT

23

KD0-25000-7340

SWITCH ASSEMBLY

N/I

KD7-23920-0130

WASHER ASSEMBLY

N/I

KD7-09210-1000

SEAL ASSEMBLY
