Запчасти Komatsu PC400LC-5 ГЕНЕРАТОР ( A) ЭЛЕКТРИКА

|$0

600-821-7370

ALTERNATOR - 35 A

1

KD1-0456-63037

BEARING, BALL

2

KD0-35100-0110

ROTOR ASSEMBLY

3

KD1-0416-04160

KEY, WOODRUFF

4

KD1-33923-0780

COLLAR

5

KD1-0055-06162

SCREW

6

KD0-35926-0060

RETAINER

7

KD1-33951-0610

PACKING

8

KD1-33926-0750

RETAINER

9

KD1-0456-63054

BEARING, BALL

10

KD1-33926-0730

RETAINER

11

KD1-33923-0810

COLLAR

12

KD1-33926-0770

RETAINER

13

KD1-35761-0060

COVER

|$14

KD0-35700-0220

REAR BRACKET

14

KD1-33943-0980

BUSHING, INSULATOR

15

KD0-35710-0230

BRACKET, REAR

16

KD7-44000-0907

REGULATOR ASSEMBLY

17

KD1-33786-0420

PLATE, TERMINAL

18

KD0-0056-05162

SCREW

19

KD0-35928-0020

STOPPER

20

KD0-0080-05502

BOLT

21

KD1-0550-05013

PLATE, TERMINAL

22

KD1-09102-0010

PLATE, INSULATOR

23

KD0-33730-2190

RECTIFIER ASSEMBLY

24

KD1-33928-0230

STOPPER

25

KD1-33943-0760

BUSHING, INSULATOR

26

KD1-33785-2690

WIRE

27

KD0-0080-05602

BOLT

28

KD0-0080-05102

BOLT

29

KD0-35120-0050

FIELD COIL ASSEMBLY

30

KD1-33200-1230

STATOR ASSEMBLY

31

KD1-33310-1060

BRACKET, FRONT

32

KD0-0275-06852

BOLT

33

KD1-33421-0510

FAN

34

KD1-35411-0040

PULLEY, ALTERNATOR

35

KD1-0330-16012

WASHER

36

KD1-0335-16002

WASHER, LOCK

37

KD0-0280-16022

NUT
