Запчасти Komatsu PC400LC-5 ГЕНЕРАТОР ( A) HARDENED ШКИВ ЭЛЕКТРИКА

Схема запчастей Komatsu PC400LC-5 - ГЕНЕРАТОР ( A) HARDENED ШКИВ ЭЛЕКТРИКА
19
18
17
15
16
13
12
11
10
9
8
3
14
7
9
6
4
5
25
26
1
2
20
22
27
21
23
24

Артикул

Название

Примечание

Количество

|$0

600-821-5640

ALTERNATOR, 25 A - WITH HARDENED PULLEY

1

KD0-35100-0080

ROTOR ASSEMBLY

2

KD1-09201-0460

BEARING, BALL - REAR

3

KD1-0456-63057

BEARING, BALL - FRONT

4

KD1-0416-04160

KEY

5

KD1-33923-0780

COLLAR

6

KD0-35926-0060

RETAINER

7

KD1-33926-0750

RETAINER

8

KD1-33926-0730

RETAINER

9

KD1-33951-0610

PACKING

10

KD1-33923-0810

COLLAR

11

KD1-33926-0770

RETAINER

12

KD0-35200-0060

STATOR ASSEMBLY

13

KD0-35310-0021

FRONT BRACKET ASSEMBLY

14

KD0-0275-06802

BOLT, THROUGH

15

KD0-35411-0180

PULLEY, ALTERNATOR - HARDENED

16

KD1-35421-0030

FAN

17

KD1-0330-16012

WASHER

18

KD1-0335-16002

WASHER

19

KD0-0280-16022

NUT

20

KD0-35120-0040

FIELD COIL ASSEMBLY

|$21

KD0-35700-0130

REAR BRACKET ASSEMBLY

21

KD0-35710-0140

BRACKET

22

KD0-35730-0080

RECTIFIER ASSEMBLY

23

KD1-35761-0060

COVER

24

KD1-33943-0770

BUSHING

25

KD1-09102-0010

PLATE

26

KD1-33943-0760

BUSHING

27

KD7-44000-0900

REGULATOR

Выбрано товаров: 29
