Запчасти Komatsu PC400LC-5 ТОПЛ. НАСОС ПОДКАЧИВАЮЩ. НАСОС ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC400LC-5 - ТОПЛ. НАСОС ПОДКАЧИВАЮЩ. НАСОС ТОПЛИВН. СИСТЕМА
17
14
15
16
16
13
11
13
12
8
12
10
20
21
22
9
22
19
7
10
1
2
22
3
18
4
6
5

Артикул

Название

Примечание

Количество

|$2

ND092100-1761

PUMP ASSEMBLY, ENGINE FUEL INJECTION PUMP FEED

1

ND092120-0370

HOUSING

2

ND092168-0150

ROD, PUSH

3

ND092171-0011

PISTON

4

ND092182-0060

SPRING, PISTON

5

ND092184-0021

PLUG, CHAMBER

6

ND949018-1240

WASHER

7

ND092174-0050

TAPPET

8

ND092176-0010

ROLLER, TAPPET

9

ND092178-0040

PIN, ROLLER

10

ND092179-0070

BLOCK, SLIDING

11

ND949072-0940

RING, SNAP

12

ND092121-0011

VALVE, CHECK

13

ND092124-0010

SPRING, VALVE

14

ND092130-0220

PUMP ASSEMBLY, FUEL INJECTION PUMP PRIMING

15

ND092126-0010

PLUG, CHAMBER

16

ND092125-0010

GASKET

17

ND090061-0011

COVER

18

ND949180-0020

SCREW

19

ND949181-0420

NIPPLE

20

ND092223-0070

SCREW

21

ND092220-0040

FILTER, ENGINE FUEL INJECTION PUMP FEED PUMP

22

ND090222-0070

WASHER

Выбрано товаров: 23
