Запчасти Komatsu PC400LC-5 ТОПЛИВН. НАСОС И РЕГУЛЯТОР ЗАДН. КРЫШКА И КОМПОНЕНТЫ ТОПЛИВН. СИСТЕМА

|$1

ND190800-2460

GOVERNOR, FUEL PUMP - REAR

1

ND190890-0140

COVER

2

ND091031-0150

NUT, CAP

3

ND091006-0150

SCREW, ADJUST

4

ND090944-0310

BUSHING

5

ND090989-0010

SHAFT

6

ND090991-0010

PLUG

7

ND090560-0200

CAPSULE, FULL STOP

8

ND090923-0060

NUT, LOCK

9

ND090880-0140

LEVER, SWIVEL

10

ND090892-0160

BUSHING

11

ND949140-5760

O-RING

12

ND949071-0090

WASHER, SNAP

13

ND949047-1760

BOLT

14

ND949047-1750

BOLT

15

ND949150-2690

SEAL, OIL

16

ND091071-1420

LEVER, ADJUST

17

ND091071-4150

LEVER, ADJUST

18

ND949047-1190

BOLT

19

ND091094-0060

CAP

20

ND949047-1790

BOLT

21

ND091051-0480

PLATE

22

ND91418-06141

BOLT

23

ND91418-06161

BOLT

24

ND090241-0010

WASHER

25

ND091031-0030

NUT, CAP

26

ND949062-1270

PACKING

27

ND949130-0030

KEY, WOODRUFF

28

ND090944-0440

BUSHING

29

ND949013-8210

WASHER, (0.3 MM)

|$31

ND949013-8220

WASHER, (0.6 MM)

|$32

ND949013-8230

WASHER, (0.9 MM)

30

ND949050-3390

NUT

31

ND949018-1020

WASHER

32

ND949140-5740

O-RING
